Technology Articles

2023-03 Semiconductors Toshiba Semiconductor and Storage

[Mär 10 2023] Toshiba's TSOP6F encapsulated mosFeTs provide power density and performance in small packages. These products are suitable for applications such as motor control in consumer and industrial equipment. In addition, AEC-Q101 compliance makes the product suitable for automotive and other high reliability applications. Range is -40 V to 100 V with N channel and P channel options and RDS(ON) as low as ...

2023-03 Semiconductors Panasonic

[Mär 9 2023] Panasonic's PAN1781 series RF modules are Panasonic's high technology RF module devices with Nordic nRF52820 microcontroller. This new addition to Panasonic's Wireless Connectivity RF module product line is ideal for wireless connectivity applications in the Internet of Things. The Nordic SDK is the best way to easily implement applications on the PAN1781 family of RF modules. In addition to the ...

2023-03 Semiconductors Panasonic

[Mär 9 2023] Panasonic's EV series automotive relays are rated for DC loads ranging from 10 A at 450 VDC to 300 A at 450 VDC in an incredibly compact and lightweight design. High contact reliability is achieved by sealing contacts in hydrogen to prevent contact oxidation and maintain a dustproof and waterproof environment. The AEVG16012 can withstand rated short-circuit currents up to 4,500 A and has A rated ...

2023-03 Sensors Molex

[Mär 9 2023] Each industry faces different power connector challenges. A faulty connector will cause an electrical failure. Loose terminals or other possible assembly errors can result in dangerous vehicle brake failure. As data grows everywhere, PCB makers need to use more electronic components in smaller board Spaces; Small size and high power density do not go hand in hand. Molex's Ultra-Fit power connecto ...

2023-03 Power Murata

[Mär 9 2023] Murata's LBAD0ZZ1SE-743 cellular terminal equipment features highly integrated (MCU, eSIM and LTE-M/NB1 modem), certified terminal equipment with antenna connectivity for easy integration with many different types of applications. The technology is used for iot devices to connect directly to a 4G network without a gateway and typically run on battery power. LTE-M includes eMTC (Enhanced Machine-T ...

2023-03 Semiconductors Infineon Technologies

[Mär 8 2023] Infineon's MA2304DNS/MA2304PNS is a 2 x 37 W audio amplifier family that uses MERUS multilevel switching amplifier technology to achieve excellent efficiency at both low and high output power. Multilevel switches relax EMC requirements and enable inductorless applications at a lower cost. A high order internal feedback loop ensures low THD and high PSRR for excellent audio performance. The integr ...

2023-03 Power Schaffner EMC

[Mär 8 2023] Schaffner's FN3025 and FN3026 are designed for small and medium-sized industrial equipment with limited space. They provide very low leakage current. The DIN rail version (FN3026) is suitable for the popular TS 35 DIN rails on panel buildings and electrical cabinets. HP type has slightly better performance than HL type and higher ground leakage rate. They are rated at 520 volts. They have 10a, 20 ...

2023-03 Sensors Amphenol Piher Sensing Systems

[Mär 8 2023] Amphenol Piher Sensing Systems' PS2P-ARC position sensors are not affected by radial and axial clearance on the pivot joint, thus avoiding poor operating performance and labor intensive maintenance schedules due to unaligned. Magnets are connected to pivot joints for rotating parts, and electronic modules are connected to the case (and vice versa). Sensors are easy to install without any gears or ...

2023-03 Sensors Amphenol Piher Sensing Systems

[Mär 8 2023] Amphenol Piher Sensing Systems' PSCM is a non-contact multi-turn rotating position sensor based on Hall effect technology, which is a cost-effective alternative to absolute encoders. It is also well suited for replacing drawstring encoders by converting linear motion into angular position. In the case of power failure, the sensor will retain the last measured position. This compact yet rugged sen ...

2023-03 Power Molex

[Mär 7 2023] Molex's ACB6+ Series SlimStack board-to-board Connector offers upgraded performance with up to 5.0A power stud fully armored housing protection. With 0.35 mm pitch and 0.60 mm height, the connector provides plug-in guidance and electrical contact guarantees for superior reliability in challenging applications. The contact area is separated from the welding area (terminals and nails are separated ...

2023-03 Sensors TDK

[Mär 7 2023] TDK Corporation's EPCOS B43652* series bite-type aluminum electrolytic capacitors feature a very compact size and very high ripple current carrying capacity. Designed for a maximum rated voltage of 450 VDC, the RohS-compatible capacitors come in seven models covering a capacitance range from 270 µF to 820 µF. A typical application of these capacitors with high CV products is the DC link circuit o ...

2023-03 Power Stewart Connector

[Mär 7 2023] Stewart Connector delivers reliability and functionality with its SealJack modular cable application series and RJ45 modular jack. The portfolio responds to the connectivity requirements for devices as Ethernet applications move from typical office conditions to harsh environments in the Internet of Things (IoT) era. Cable application series The SealJack Cable Application Series is IP67 Class pre ...
