Technology Articles

2023-03 Connectors Yageo

[Mär 18 2023] The PG2290, PGL6395 and PA5615 series of high current, low DCR inductors from Pulse Electronics, YAGEO, Inc., are combined for single-phase PoL and polyphase step-down converters, processors, memory modules for servers, data centers, network systems and graphics cards. fpga and ASICS power supply. All three series use the latest high-frequency materials that reduce core losses, reduce DCR, and pr ...

2023-03 Semiconductors STMicroelectronics

[Mär 18 2023] STM32WB1MMC wireless module is a cost-effective Bluetooth LE application integration solution. The STM32WB1MMC module imparts the entire reference design into the antenna, with the option of using an external antenna. The module is widely certified by FCC, CE and other EMC regulations. Based on the STM32WB15 WLCSP49 package, this module provides up to 27 GPIOs suitable for a range of peripherals ...

2023-03 Power Texas Instruments

[Mär 17 2023] Texas Instruments' TPSM63610 is a highly integrated 36v, 8 a DC/DC solution that combines power MosFETs, shielded inductors and passivity in an enhanced HotRod QFN package. The module features VIN and VOUT pins located in the corners of the package to optimize the placement of input and output capacitors. Four larger heat pads below the module make the layout simple and easy to manufacture. With ...

2023-03 Sensors Cornell Dubilier Electronics (CDE)

[Mär 17 2023] Cornell Dubilier's Model 944L DC Link capacitor is designed for fast switching power supply conversion applications. Their low inductance structure and low loss winding technology make them ideal for the design of the next generation of high power intensive inverters and converters. Sturdy plastic housing with integrated mounting flanges, threaded studs, or insert termination options for easy, sa ...

2023-03 Power Texas Instruments

[Mär 17 2023] The OPA593 is a high-voltage (85 V), high-precision, wide-band (10 MHz), high-output current (250 mA), unity-gain stable power amp that uses laser fine-tuning technology to improve offset voltage (20µV typical) and offset voltage drift (0.4µV/°C typical), avoiding the need for calibration. The amplifier has a Mux-friendly input that enables differential input voltage ranges across the supply trac ...

2023-03 Power Pulse Electronics

[Mär 17 2023] The PMS9505 series of Pulse Electronics from YAGEO has a unique construction. The primary winding is moulded into a plastic base to form a strong insulating barrier to achieve enhanced insulation, conforming to IEC60664/IEC60950-1, with operating voltages up to 300 VRMS. The PMS9505 features current sensing from a low DCR primary, allowing a current rating of 30 ARMS with turning ratios ranging f ...

2023-03 Power Renesas Electronics America

[Mär 17 2023] Renesas RA4E2 is the most optimized product in the RA4 range. It is based on the 100 MHz Arm®Cortex®-M33 core and offers a smaller package, lower pin count options, and a more optimized feature set than the existing RA4E1. It maintains the same performance range as several interfaces, such as I³C, CAN FD, and HDMI CEC, which were previously unavailable on RA4 devices. The RA4E2 can be the first e ...

2023-03 Semiconductors Texas Instruments

[Mär 16 2023] Texas Instruments' MCT8329A offers a single-chip, code-free sensorless ladder solution for three-phase brushless direct current (BLDC) motors that require high-speed operation or very fast start-up times. The device provides three half-gate drivers, each capable of driving both high - and low-side n-channel power MosFeTs. The device uses an internal charge pump to generate the correct grid drive ...

2023-03 Optoelectronics Taitien

[Mär 16 2023] Taitien's LoRa and LoRaWAN application-centric crystals provide tight tolerances for demanding operating environments, with initial accuracy of ±10 ppm and temperature stability of ±10 ppm in the range -40°C to +85°C. The XX, XY, XZ and X3 series have low acceleration or g sensitivity, and are standard with 26 MHz and 32 MHz. These output frequencies are used for long-range wireless data transmis ...

2023-03 Semiconductors Analog Devices

[Mär 16 2023] ADI's LT7200S is A four-channel, high-efficiency single-chip synchronous step-down regulator capable of pumping/pulling 5 A current into a load per channel. Due to its constant frequency, current mode architecture, and phase-locked controlled timing, it is ideal for high step-down ratio applications that operate at high frequencies and require fast transient responses. The LT200S 'multi-channel f ...

2023-03 Sensors Bourns

[Mär 16 2023] The Bourns AD and SD series resetable Miniature thermal fuse (TCO) circuit breaker devices are the first class of Bourns TCO devices that have passed the pressure test of the AEC-Q200 standard. The AD and SD series' advanced overheating protection technology makes them ideal solutions for a wide range of applications such as heaters, motors, cables and printed circuit board components. They also ...

2023-03 Semiconductors Texas Instruments

[Mär 16 2023] Texas Instruments' TPS92622-Q1 dual-channel LED driver includes a unique thermal management design to reduce temperature rise on the device. The TPS92622-Q1 is a linear driver powered directly from the car battery, with large voltage variations and a full current load of up to 150 mA per channel output. External shunt resistors are drivers that share output current and dissipated power. The devic ...
