Technology Articles

2023-04 Power Renesas Electronics America

[Apr 7 2023] The RAA2S4252B is a member of the Renesas CMOS integrated circuit family for high-precision amplification and sensor-specific correction of differential bridge sensor signals. The RAA2S4252B features 900 maximum analog preamplification and analog Sensor offset correction (XSOC), which can be adjusted for almost all resistance Bridges. Conditioning calculations are performed with a 16-bit RISC mic ...

2023-04 Power ECS

[Apr 7 2023] ECS 'ECX-1637B2 series of Surface Mount (SMD) crystals are packaged in industry standard 2.0mm x 1.6mm x 0.45mm 4-pad ceramic. These electronic components offer a wide frequency range from 16 MHz to 50 MHz. They offer tight stability options of ±10ppm, tolerance of ±10ppm, and first year aging at low ±2ppm at +25°C±3°C, with the option of an extended operating temperature range. The standard ECX- ...

2023-04 Sensors TDK-Lambda

[Apr 7 2023] TDK Lambda's CCG1R5 (1.5W) and CCG3 (3W) components can be operated at full load in the temperature range of -40°C to +85°C under convection-cooled conditions. These models consist of 36 voltage and current combinations and have 3.3V, 5 V, 12 V, 15 V and dual ±12 V and ±15 V outputs. Dual output models can also be connected to 24 V and 30 V power supplies. They can all operate at 4.5 V to 18 V, 9 ...

2023-04 Sensors Amphenol LTW

[Apr 7 2023] Amphenol LTW's overpressure release vent comes in a metal and plastic casing that balances the pressure inside and outside the sealed casing to prevent shortening the service life of the device and prevent potential damage to the internal components, performance degradation, or sudden heat/pressure rise of the battery module resulting in an explosion. IP68/IP69K waterproof protection and hydropho ...

2023-04 Sensors ABB Embedded Power

[Apr 3 2023] ABB Embedded Power's MLX and SLX series modules operate over a wide input voltage range from 7 VDC to 14 VDC, providing PMBus programmable output voltages from 0.45 VDC to 2.0 VDC. The DLynx III power module features an advanced PID-based adjustable digital control loop that helps ensure loop stability, provides fast transient response, and reduces output capacitance requirements. Additional SLX ...

2023-04 Sensors Phoenix Contact

[Apr 3 2023] Phoenix Contact's LPTA 16 series provides a tool-free lever connection technology ideal for field device connections. The consistent PCB terminal block product line combines lever-driven high ease of use with reliable insertion spring connections. In the growing market for renewable energy, electric drives, and electric charging infrastructure, drives need to be connected quickly and securely. Fe ...

2023-04 Power XP Power

[Apr 3 2023] XP Power's ASB160 Series low-profile, all-brick, baseboard cooled AC/DC power supply requires no external components. The series includes built-in EMC filters, AC fuses, and mass storage capacitors to provide complete AC/DC power solutions that can be installed in industrial and semiconductor manufacturing applications. The ASB160 series reduces the failure rate through effective heat dissipation ...

2023-04 Power KEMET

[Apr 3 2023] KEMET's C700 safety rated disk capacitors are designed for interference suppression AC line filtering applications. These capacitors have internationally recognized safety certifications and are ideal for applications that need to keep potentially destructive or destructive line transients and EMI away from sensitive equipment. They are also an ideal solution when line interference needs to be su ...

2023-04 Power Renesas Electronics America

[Apr 3 2023] Renesas's RAA271082 multitrack power supply IC features one primary high voltage synchronous step-down regulator, two secondary low voltage synchronous step-down regulators, and one LDO regulator. It provides four overvoltage (OV) and undervoltage (UV) monitors, I2C communications, a universal I/O pin and a dedicated reset output/failure indicator. A 4 mm x 4 mm 24 pin step cut QFN (SCQFN) packag ...

2023-04 Power KEMET

[Apr 3 2023] KEMET's full range of axial and radial coronal capacitors for automotive applications includes the Ultra High CV PEG227 and PEH227 series. KEMET's capacitors have excellent electrical performance and high energy storage capacity. They are rated for temperatures ranging from -40°C to +125°C or -40°C to +150°C at derated voltages. The series uses a polarized all-welded design with tinned copper lea ...

2023-03 Power Texas Instruments

[Mär 23 2023] The TL317 is an adjustable three-pole voltage regulator capable of delivering 100 mA in the 1.25V to 32V output voltage range. It is very easy to use and only requires two external resistors to set the output voltage. The regulator provides complete overload protection and is only available in integrated circuits. Current limiting and thermal overload protection are included on the chip. All over ...

2023-03 Semiconductors Multi-Tech Systems Inc.

[Mär 23 2023] Nuvoton's nummicro M032 family is a 32-bit microcontroller based on an Arm Cortex-M0 cpu with a 32-bit hardware multiplier/divider. They feature operating voltages of 1.8 V to 3.6 V, 5 V I/O tolerances, and up to 48/72 MHz in the range -40°C to +105°C. The M032 series provides a comprehensive solution for crystallotless USB applications requiring 1.8V interface connectivity, featuring enhanced fa ...
