Technology Articles

2023-01 Semiconductors Microchip Technology

[Jan 18 2023] Microchip Technology's MCP19123 Power analog controller is a medium-voltage (4.5V to 40V) analog synchronous step-down PWM controller with an integrated 8-bit PIC microcontroller. This unique product combines the performance of a high-speed analog solution with the configurability and communication interface of a digital solution. The controller provides excellent regulation accuracy, high effici ...

2023-01 Sensors Littelfuse

[Jan 18 2023] Littelfuse announced the launch of its new line of electronic fuse protection integrated circuits, which will include four multifunctional circuit protection devices. Electronic fuse protection Integrated circuits are innovatively designed to provide a wide range of power inputs (3.3V to 28V) and integrated protection. In addition to overvoltage protection, the series of electronic fuses protects ...

2023-01 Semiconductors Texas Instruments

[Jan 18 2023] Texas Instruments LMH1219 is a low-power, dual-input dual-output, adaptive equalizer with reclocker integration. It supports SMPTE video rates of up to 11.88 Gbps and IP of 10 GbE videos, enabling ultra HD video for 4K/8K applications. IN0's extended adaptive cable equalizer is designed to equalize data transmitted over 75 ohm coaxial cable and operates in a wide data rate range of 125 Mbps to 11 ...

2023-01 Power Wurth Electronics

[Jan 17 2023] WCAP-FTBP and WCAP-FTBE from Wurth Elektronik are general purpose DC film capacitors for filtering, blocking, bypass or energy storage. Both series are characterized by high volumetric efficiency and excellent self-healing properties due to the use of metallized film technology. WCAP-FTBP metallized polypropylene DC vessel (MKP) is characterized by excellent voltage resistance, 5% capacitance tol ...

2023-01 Sensors Bourns

[Jan 17 2023] Bourns has announced the addition of 12 new CSM2F series power shunt resistors, extending its product portfolio. The new series uses riveted through-hole metal sensing pins to meet the growing demand for accurate positioning of voltage test points in high-current applications. The latest Bourns CSM2F series of shunt resistor products are designed with Bourns electron beam welding resistor technol ...

2023-01 Power Bridgetek Pte Ltd.

[Jan 17 2023] The Bridgetek FT93x series by Bridgetek/FTDI is a compact SuperBridge mcu that provides flexible bridging solutions between different technologies, including USB, UART, SPI and SD host. The unique feature of the USB device port for the MCU is that in addition to supporting all standard classes, the device can simply switch to hard-coded D2xx mode, eliminating the need for a lot of complex USB enc ...

2023-01 Power Diodes Incorporated

[Jan 17 2023] Two types of precision power amplifiers (op-amps) with different signal frequencies are produced by Diodes to meet the need of advanced signal regulation in modern automobile design. The low noise ratio characteristics of DIODES AS2376Q indicate that they are optimized for high frequency applications such as on-board chargers (OBCs), DC-DC converters, battery management systems (BMS) implementati ...

2023-01 Sensors Omron Electronics Inc-EMC Div

[Jan 16 2023] Omron's E3AS photoelectric sensor improves part detection, especially when part characteristics change using time of flight (TOF) technology. Traditional triangulation methods are challenged by changing component colors, exotic profiles and varying reflectance. TOF technology detects objects based solely on the distance between them and the sensor, so it is not affected by changes in color or ref ...

2023-01 Sensors TDK

[Jan 16 2023] TDK's compact EPCOS E13EMHV series SMT transformers with high dielectric strength. This series of components is widely applicable to various DC-DC converter topologies. The electrical isolation distance complies with IEC 60664-1 and 61558-2-16 standards. The maximum operating voltage is 1000 V DC, and transient overvoltage can be tolerated up to 2500 Vpeak. And the withstand voltage between the p ...

2023-01 Sensors Analog Devices

[Jan 16 2023] The ADE9153 is a single-phase power metering automatic calibration IC mSure Automatic calibration feature allows meters to automatically calibrate current and voltage channels without using an accurate source or an accurate reference meter when shunt resistance is used as a current sensor. Levels 1 and 2 are automatically calibrated by mSure. The ADE9153 integrates three high-performance analog-t ...

2023-01 Power Maxim Integrated

[Jan 16 2023] Maxim Integrated's MAX86150 provides pleurogram (PPG) and electrocardiogram (ECG) measurements via a mobile battery-powered device for health monitoring. The MAX86150 is a biosensor module consisting of an internal light-emitting diode, photodetector, and ECG analog front end (AFE) that delivers highly accurate, FDA-approved PPG and ECG performance in compact power-saving designs that include mob ...

2023-01 Sensors Renesas Electronics America

[Jan 15 2023] Intersil's ISL8215M power module is a single channel synchronous step-down complete power supply capable of delivering up to 15 a continuous current. Operating from a single 7 V to 42 V wide input power track, the ISL8215M incorporates controllers, power inductors and MOSFEts optimized for space-constrained and battery-powered applications. With high efficiency, including optional light load mode ...
