A highly integrated high output voltage boost converter
The Texas Instruments TLV61046ADBVR is a highly integrated high output voltage boost converter. The device is suitable for a variety of demanding applications, from portable consumer electronics to high-performance industrial applications. It supports a variety of display and sensor applications, providing a powerful solution for devices requiring high output voltages.
It uses advanced current mode control technology that allows it to boost the input voltage from 1.8V to a maximum of 28V, with a typical switching current of 980mA. This efficient conversion capability enables the device to operate stably at low input voltages, significantly extending battery life.
The device is equipped with several important features, including integrated power diodes and isolation switches, output short circuit protection, output overvoltage protection and thermal shutdown protection to provide security for high-performance applications. It operates in the input voltage range from 1.8V to 5.5V and supports operating temperatures from -40 ° C to 85 ° C, making it highly adaptable to a variety of environments.
The converter also offers a wealth of peripheral features, such as internal setup of 12V output voltage and fixed switching frequency up to 1MHz. This allows the device to maintain high efficiency while reducing dependence on external components, simplifying system design. Its compact packaging and minimal external component requirements make it ideal for space-constrained portable devices.
Low power consumption is a key feature of the device, designed to minimize static current consumption and greatly extend battery life, making it ideal for battery-powered and portable devices. Its efficient output conversion reduces energy waste and maximizes device functionality while minimizing power consumption.
