Technology Articles

2023-02 Semiconductors NXP

[Feb 26 2023] ● Up to six IEEE 100BASE-T1 PHyS ● Single IEEE 100BASE-TX PHY ● Up to two MII/RMII/RGMII interfaces ● Up to four SGMII interfaces ● A host controller based on Arm® Cortex®-M7 NXP's SJA1110 family of Automotive Ethernet switches provides a rich set of security, safety and TSN features. The device is available in four models, each capable of supporting flexible modular ECUs designs for gateway, ADA ...

2023-02 Semiconductors Analog Devices

[Feb 26 2023] ADI's LTM4652 is A step-down DC-DC μModule voltage regulator with A pull/pump dual-channel ±25 A or single-channel ±50 A output switching mode with a total DC output error of ±1.5%. The LTM4652 operates in an input voltage range of 4.5V to 18V and supports dual outputs ranging from 0.6V to 7.5V, with each output set by an external resistor. The device is designed with high energy efficiency, prov ...

2023-02 Optoelectronics Bridgelux

[Feb 26 2023] For traditional LED technology, higher CRI results in lower light efficiency. Bridgelux's F90 LED product achieves CRI80 LED light efficiency with a CRI of 90 by replacing wide-band red phosphor phosphors with narrow band red potassium fluosilicate (PFS or KSF) phosphors. Lighting users can replace existing leds in lighting products with F90 leds to achieve CRI90 conversion. F90 series leds have ...

2023-02 Semiconductors Texas Instruments

[Feb 26 2023] Texas Instruments TLV61070A is a synchronous boost converter with an ultra-low input voltage of 0.5V that provides a power solution for portable devices and smart devices powered by a variety of batteries and supercapacitors. The typical valley switching current is limited to 2.5 A over the entire temperature range. The device has a wide input voltage range of 0.5 V to 5.5 V, supporting applicati ...

2023-02 Semiconductors Texas Instruments

[Feb 25 2023] Texas Instruments ISOUSB111 is a current isolated USB 2.0 compatible repeater that supports both low (1.5 Mbps) and full (12 Mbps) signal rates. The device supports automatic connection and speed detection, pull-up/pull-down reflection, and link-layer power management and can be used for plug-in USB hubs, hosts, peripherals, and cable isolation. The device also supports automatic role reversal, w ...

2023-02 Power XP Power

[Feb 25 2023] XP Power's JMR03 series ultra-compact DC/DC converters are medically certified and designed for BF and CF grade applications. From DIP24 to DIP16 modules, the base surface of JMR03 is reduced by 45%, thus providing more PCB space for the user's components. The wide input range of 4:1 provides flexibility in power selection. Reduced no-load input standby current provides longer run times in portab ...

2023-02 Semiconductors Texas Instruments

[Feb 25 2023] Texas Instruments TPS61376 is a high voltage asynchronous boost converter with input average current limiting and real load disconnection. The average input current limit threshold can be set in 0.1A to 3.0A Settings via the ILIM pin. The isolation FETs between VP and SW pins will cut the path between input and output when the device is disabled. The converter has a wide input voltage range of 2. ...

2023-02 Semiconductors Texas Instruments

[Feb 25 2023] The Texas Instruments LM5169 is a synchronous step-down converter designed to adjust over a wide input voltage range, minimizing the need for external surge suppression components. A controlled on-off time of 50 ns (minimum) helps achieve a large step-down conversion ratio that supports direct step-down from 48 V nominal input to the low rail, thereby reducing system complexity and solution cost. ...

2023-02 Semiconductors Analog Devices

[Feb 24 2023] The MAX31331 and MAX31334 Ultra-low Power RTC of DI are devices that consume ultra-low power timing currents to extend battery life. They support a variety of crystals with different capacitive load specifications (CL), which expands the pool of available crystals for the device. The device can be accessed through I2C serial interface. The MAX31331SHLD# and MAX31334SHLD# Shield Evaluation kits (E ...

2023-02 Semiconductors NXP

[Feb 24 2023] ● The onboard OpenSDA circuit supports debugging and programming using CodeWarrior ● The on-board OpenSDA circuit enables the virtual serial port ● The peripherals support rapid prototyping and include a three-axis MEMS accelerometer, six PWM, three user leds, four directly interacting user buttons, two OPAMP external feedback circuits, an SPI interface flash memory, and three resistance dividers ...

2023-02 Power Pulse Electronics

[Feb 24 2023] The LPTG600/71DMN LPT antenna family is manufactured by Pulse Electronics, a Yageo company. This family of 5G FR1, M2M, Band 71 IoT thin antennas for transmission provide superior performance. It covers the frequency range of 617 MHz to 960 MHz/1710 MHZ to 7125 MHz. The LPTNG600/71DMN series features 2 dBi and 5.5 dBi gain, dipole configurations, respectively, allowing for longer coverage and hig ...

2023-02 Semiconductors Pulse Electronics

[Feb 24 2023] The PGL6477 and PGL6478 series of high-current, low-DCR inductors from YAGEO's Pulse Electronics are available for single-phase point-of-load (PoL) and polyphase step-down converters. Power processors, memory modules, FPGas and ASics in servers, data centers, network systems and graphics cards. The PGL6477 and PGL6478 series use Pulse Electronics' power magnetic bead technology and are built with ...
